We manufacture

Carbon Fiber components for

Moth

C-Tech spars have the highest possible stiffness and strength to weight ratios and are produced to exacting standards with consistent bend curves. This is achieved by a combination of fibre selection and placement. The fibres are all high modulus prepreg carbon fibre. These are placed with no crimp (interweaving of layers) and no laps along the the taper. This greatly improves mast strength and consistency of flex curve.

Carbon Product Range for
Moth
Moth Mast
Moth Mast
  • 04
  • 04B
  • 04C
  • 04C Minus
  • 04D
Moth Bent Boom
Moth Bent Boom
  • Bent boom
Moth Foils
Moth Foils
  • Rudder vertical
  • Rudder elevator
  • Main vertical
Moth Tube Kit
Moth Tube Kit
  • Compression strut
  • Bowsprit
  • Wand
  • Forward and aft bars
  • Outer bars (including sleeves)
Moth PlateBattens
Moth PlateBattens
  • Plate Battens

Working with C-Tech for the past year has been an absolute joy. In a development class like the Moth, adapting quickly to the latest developments is absolutely essential to stay on top of the fleet and C-Tech has constantly been looking for new ways to get every single bit of performance out of the boat.

Aero drag reduction has been the main scene of developments in the Moth class. C-Tech’s latest product range is taking this to the next level. It is a major step in the right direction and I am very excited for what is to come.

Nicolai Jacobsen

Carbon fibre products for

Moth

Moth Mast

Enquire
About

C-Tech has a range of Moth masts that can be used with all current rig and manufacturer configurations to suit all sailor weights. Standard specifications can be tweaked for individual preferences. The 04 mast range is effectively the 03 range with the reinforcing laminates shifted approximately 400mm further up the mast. This gives the mast a more even bend. The 04 model also address the issue some sailors were experiencing in certain conditions with the 03 masts blading out the sail in the head whilst not flattening in the lower half. All masts can be ordered with tall rig or deck sweeper configuration. A male mast base adapter option is also available.

Products
About
Model Softness Advantages Target Weight Specific Weight
04 Stiff Offers excellent leech control and very fast downwind Sailors 105kg+ Sailors 95kg+ (up to 12knots)
04B Medium - 10% softer than 04 Same bend profile Sailors 90kg+ Sailors 83kg+ (up to 12knots)
04C Soft - 17% softer than 04 Same bend profile Sailors 75-90kg
04C Minus Very soft - 21% softer than 04 Same bend profile Sailors 60-75kg Sailors up to 95kg (over 20knots)
04D Very very soft - 28% softer then 04 Same bend profile Sailors up to 65kg Sailors up to 83kg (over 20knots)

Moth Bent Boom

Enquire
About

The latest C-Tech Bent Moth Boom supplied for boats configured with a low mast post with a 15° bend. We also have a boom with a 9° bend suitable for the old high post Mach 2 configuration. The boom is now available with the mainsheet and vang as separate fittings to suit new DS sails. The mainsheet can be placed either side of the boom kink. We also offer a single fitting where the mainsheet attachment incorporates the vang attachment with a titanium through bar.

Products
About

Moth Foils

Enquire
About

C-Tech is the manufacturer for Mackay Boats Bieker Moth vertical foils. These are an integral part of the boats international success and are made from high modulus pre-preg carbon fibre with a foam core for incredible stiffness. They are cured in our autoclave using precision alloy tooling. This process means we can achieve maximum stiffness possible for a given sectional area. This is part of the Mackay Boats Bieker Moth advantage.

Vertical foils including, rudder elevator, rudder vertical and main vertical.

Products
About

Moth Tube Kit

Enquire
About

Full tube kit, or customised tube kits available for individual requirements.

Products
About

A standard tube kit can consist of:

  • Forward and aft bars
  • Outer bars (including sleeves)
  • Compression strut
  • Bowsprit
  • Wand

Moth PlateBattens

Enquire
About

C-Tech have developed moth PlateBatten sets with each of the main sailmakers. The battens are optimised for strength to weight with a mixture of carbon and S-Glass. The draft positions and stiffness's have been tuned in over time to keep up with changing rig designs. All battens have the taper designed into the laminate which is cured in our autoclave and CNC cut to width. C-Tech is the Moth batten supplier to Doyle, North and Lennon Performance sails.

Products
About
